E-pack200
Dual-channel DMR Ad-hoc Portable Repeater
Hytera E-pack200 is a DMR ad-hoc dual-channel repeater for man-pack, the repeater adopts wireless interconnection technology to quickly create multi-hop narrowband networks through cascading connection, free of any IP link such as fiber optic and microwave. The repeater can repeat voice services on dual channels at the same time. The repeater is compatible with Hytera or third-party DMR Tier 2 radios. Moreover, the repeater is easy to hold and has a lightweight design.
Highlights
Antennas for dual mode operation
Visible dual narrowband antennas to support independent dual-channel operation
Wi-Fi communication
Enables wireless programming via WiFi connection.
Power Supply Port and Palm Microphone Jack
For connecting a power supply to charge the battery or to operate without a battery. The Palm Microphone Jack allows local operation.
More antennas than you see
Built-in LTE, WiFi and GPS antenna
Power, Work Status and Channel Indicators
Indicates whether the device is in opration, normal operation mode or alarm operation mode and which channels are in operation.
Dual Channel Working
Supports two independant communication links.
Reliable Quality
Hytera E-pack is strictly compliant with MIL-STD-810 C/D/E/F/G standards and water and dust-proof rating to IP67, ensuring outstanding performance even in harsh environments.
Battery Life Indicator
One-touch to view remaining battery capacity
Functions
FAST DEPLOYMENT, CREATE NETWORK IN SECONDS
In emergency situations, every second counts. The E-pack200 repeater supports push-to-start for quickly and automatically establishing an independent network after power-on so as to efficiently extend radio coverage.
DUAL CHANNEL VOICE TRANSMIT
The repeater can repeat voice services on two channels simultaneously using 4 independent carrier frequencies (channel spacing: 12.5 kHz).
REMOTE MANAGEMENT, KEEP NETWORKING STATUS ALWAYS KNOWN
The ad hoc network created by the E-pack200 repeaters can be monitored by the network management system including the network topologies and the electric field strength of the E-pack200.
WIRELESS MOBILE AD-HOC NETWORKING
The Hytera E-Pack can create a wireless ad-hoc network, in which there are a maximum of 31 nodes. The ad-hoc network is self-configuring and dynamic in which E-Pack nodes are free to move.
BLIND AREA COVERAGE
Due to the high output power of the E-pack, communications will not be affected by the topology of the area, different floors or obstacles etc.
FREE OF ANY IP LINK, FLEXIBLE TOPOLOGY NETWORKING
The repeater adopts wireless interconnection technology to quickly create multi-hop narrowband networks through cascading connection, free of any IP link such as fiber optic and microwave.
LTE LINK AS BACKUP, OFFER A WAYS-RELIABLE COMMUNICATION SOLUTION
When the PMR network is down, the E-pack200 repeater with a SlM card can keep repeating calls or data over the LTE network. Also, it can access the command and dispatch system.
DATA ENCRYPTION, PROTECT DATA AND DEVICE
The E-pack200 repeater has multiple security mechanisms such as authentication, software and hardware encryption to protect the data and privacy. It can be disabled temporarily or permanently through the dispatch and command system to prevent unauthorized access.
Accessories for E-pack200
Included as standard with E-pack200
Related products that work with the E-pack200
DMR Systems
TETRA Systems
Technical Specifications
General
- Protocol
- ETSI DMR Tier ll
- Networking capacity
- 31
- Rated voltage
- 14.8V
- Input voltage
- 90-264VAC; 11.4-16.8VDC
- Battery capacity
- 148Wh
- Channel Spacing
- 12.5kHz
- Frequency stability
- ±0.5ppm
- Antenna impedance
- 50Ω
- Dimensions (LxWxD)
- 211 x 62 x 235mm
- Weight
- 3.1Kg (with battery)
Receiver
- Static sensitivity
- -122 dBm @ 5% BER
- Adjacent channel selectivity
- ETSI: 60 dB @12.5 kHz / 70 dB @25 kHz
- Intermodulation response rejection
- ≥ 70 dB
- Spurious response rejection
- ≥ 70 dB
- Blocking
- 84 dB
- Spurious emission (antenna port, idle mode)
- 9 kHz to 1 GHz 57 dBm
- 1 GHz to 12.75 GHz 47 dBm
Transmitter
- Output Power
- 1W/5W/10W per channel, 20W in total
- Adjacent Channel Power
- 60dB@12.5kHz 70dB@25kHz
Environmental
- Operating temperature
- -30°C to +60°C
- Storage temperature
- -40 °C to +85°C
- Waterproof & Dustproof
- IP67
- Shock and Vibration
- MIL-STD-810 C/D/E/F/G
- Humidity
- MIL-STD-810 C/D/E/F/G
Location Service
- GNSS
- GPS
- TTFF (time to first fix) cold start
- < 1 minute
- TTFF (time to first fix) hot start
- < 10 seconds
- Horizontal accuracy
- < 10 meters
