PD505 (Discontinuation Date: March 31st, 2024)

Handheld | DMR

Highlights

diagram indicating highlights of PD505 (Discontinuation Date: March 31st, 2024)

Clear Communications

Superior audio quality, even in noisy environments, is delivered via a powerful loudspeaker and noise cancelling technology

Safer Workforce

The emergency mode and lone worker features offer additional safety

Maximise Channel Capacity

Hytera patented Pseudo-trunking technology dynamically utilizes the two timeslots available on a DMR frequency to make efficient use of your channel capacity

Rugged and Reliable

IP54 rated against dust and water, certified to meet US military standards of impact, temperature and humidity

Long Battery Life

Operating time of approximately 16 hours in digital mode

Functions

Created with Sketch. Roaming

This feature allows the radio to switch between sites on Multi-site Conventional and XPT systems, ensuring seamless communication.

Created with Sketch. Radio Check

Allows other radio users to check if a radio is available.

Created with Sketch. Pseudo Trunking in DMO and RMO

Using pseudo-trunking, a Hytera patented technology, slots can be shared to improve capacity usage with transmissions either direct to handset or to repeater.

Created with Sketch. RRS

Radio Register Service, allowing a dispatching application to see when a radio is switched on or switched off.

Pd50 X 3

Created with Sketch. Stun / Unstun

You can disable/enable the radio remotely, ideal if a device is lost, stolen or being misused.

Created with Sketch. Emergency Mode

Raise an alarm with top priority to a base station or to other radios with the pre-programmed emergency mode, identifying the ID of the person issuing the alarm. Also receive emergency notifications.

Created with Sketch. Quick Text Messages

Pre-programmed via the Customer Programming Software and stored in the quick text menu ready to send to contacts.

Created with Sketch. XPT

Hytera XPT (Extended Pseudo Trunking) enables you to use limited spectrum resources more efficiently, dynamically assigning channel resource without needing a dedicated control channel.

Accessories for PD505 (Discontinuation Date: March 31st, 2024)

Included as standard with PD505 (Discontinuation Date: March 31st, 2024) Included as standard with PD505 (Discontinuation Date: March 31st, 2024)

Battery

Antenna

Charger & Power

Mounting

Carrying

Audio

Cables

Related products that work with the PD505 (Discontinuation Date: March 31st, 2024)

Technical Specifications

General

Frequency Range
VHF: 136-174MHz UHF1: 400-470MHz UHF3: 350-400MHz
Channel Capacity
256 (16 zones with 16 channels per zone)
Digital Protocol
ETSI-TS102 361-1,2 & 3
Battery Life (5-5-90 Duty Cycle)
1500mAh , Analogue 11h, Digital 16h
Dimensions(W×H×D)
115 x 54 x 27mm
Weight
Approx 260g (1500mAh Li-ion)
Display
NO
Keypad
NO
Programmable Buttons
1

Environmental Specifications

Dust & Water Intrusion
IP54 Standard

Features

RRS
YES (V7.06.01.006 firmware)
GPS
NO
Telemetry
NO
Option Board
NO
Intrinsically Safe Option
NO
Bluetooth Audio
NO
Alert Call
YES (decode only)
Remote Monitor
YES (decode only)
Stun/Unstun
YES (decode only)
Priority Interrupt
YES
IP Site Connect
YES
5 Tone Signalling
YES
2 Tone Signalling
YES
HDC1200 Signalling
YES
DTMF (Phone Patch)
NO
Intelligent audio
YES
VOX
YES
Priority Scan
YES
GPS SMS
NO
Emergency Mode
YES (V7.06.01.06 firmware)
Vibration
NO
Lone Worker
YES (V7.06.01.06 firmware)
Mandown
NO
Scrambler (Analogue)
YES
Voice Interrupt
Yes(TX Interrupt for voice call, emergency call, remote dekey, text message.)
Digital Encryption
Basic encryption as standard (10, 32 & 64 character keys)Advanced encryption NO
Multiple Key Encryption Decode
YES
Multilanguage Menu
NO
Power on & off user logo programming
NO
Voice Interrupt
Yes (TX Interrupt for voice call, emergency call, remote dekey, text message.)
No of Contacts (Conventional)
Digital 1024 Analogue 2-Tone 32 Analogue HDC1200 N/A Analogue 5-Tone N/A
Text Messaging
256 characters (via Quick Text only)
MPT1327 / 1343 Trunking
NO
Tier 3 Trunking
NO
Over-the-Air Programming
NO
Analogue Only Version
Not Available
Wireless Charging
NO
RFID Reader
NO
Mixed Mode Operation
NO
Data Services via Bluetooth
N/A
