PD985 (Discontinuation Date: March 31st, 2024)
Highlights
Full Duplex Call
Send and receive communications simultaneously to enable a conversation, rather than a classic one-way transmission
Rugged and Reliable
Dust and waterproof, rated IP68, sustaining performance in harsh environments
Wireless Connectivity
Supports Bluetooth 4.0 for audio connectivity and programming
Clear Communication
Thanks to the latest audio processing technology and in-built speaker, the PD985 offers you outstanding audio quality and noise cancellation
Increased Coverage
Using the handset to retransmit communications across a site via the innovative single frequency repeater mode (licenced)
Functions
Bluetooth Audio
Bluetooth 4.0 for wireless connectivity to audio devices to improve user experience.
Pseudo Trunking
Using pseudo-trunking, a Hytera patented technology, slots can be shared to improve capacity usage with transmissions either direct to handset or to repeater.
XPT
Hytera XPT (Extended Pseudo Trunking) enables you to use limited spectrum resources more efficiently, dynamically assigning channel resource without needing a dedicated control channel.
Full Duplex Calls
Have a conversation on a call rather than a classic one-way transmission
Voice Recording
Record your transmission and call data for future analysis. Requires micro SD card and separate application for playback, chargeable licence.
Single Frequency Repeater
Utilise your PD985 radio as a repeater to improve coverage across your site (chargeable licence)
Man Down
Optional (PD985G only), the man down feature will let you know if the radio has been tilted past a certain angle. This may happen for instance if the radio user has fallen over or is unconscious or injured. The alarm will be triggered after a warning is issued to the user.
Lone Worker
The lone worker feature uses a timer in the radio to measure inactivity. If the timer expires, a warning is issued, and if there is no response to that, the alarm is triggered.
Emergency Mode
Raise an alarm with top priority to a base station or to other radios with the pre-programmed emergency mode, identifying the ID of the person issuing the alarm. Also receive emergency notifications.
GPS
Optional (PD985G only), enabling location based services to improve safety and control.
Accessories for PD985 (Discontinuation Date: March 31st, 2024)
Included as standard with PD985 (Discontinuation Date: March 31st, 2024)
Antenna
Battery
Charger & Power
Audio
Mounting
Carrying
Cables
Other
Related products that work with the PD985 (Discontinuation Date: March 31st, 2024)
Technical Specifications
General
- Frequency Range
- UHF: 350-527MHz VHF: 136-174Mhz UHF5: 806-941MHz
- Channel Capacity
- 1024 (64 zones with 256 channels per zone)
- Digital Protocol
- ETSI-TS102 361-1,2 & 3
- Battery Life (5-5-90 Duty Cycle)
- 2000mAh, Analogue 14.5h, Digital 19.5h
- Dimensions(W×H×D)
- 131 X 54.5 X 36(mm)
- Weight
- 335g with standard battery and antenna
- Display
- 160 x 128 pixels, 65536 colours 1.8 inch, 4 rows
- Keypad
- Full Keypad
- Programmable Buttons
- 5
Receiver
- Sensitivity Analog
- 0.28μV (12dB SIN AD) , 0.22μV (Typical) (12dB SIN AD)
- Sensitivity Digital
- 0.22μV/BER5%
- Selectivity TIA-603 ETSI
- 60dB @ 12.5kHz / 70dB @ 20/25kHz (TIA-603) 60dB @ 12.5kHz / 70dB @ 20/25kHz (ETSI)
- Spurious Response Rejection TIA-603 ETSI
- 70dB @ 12.5/20/25kHz (TIA-603) 70dB @ 12.5/20/25kHz (ETSI)
- Hum and Noise
- 40dB @ 12.5kHz; 43dB @ 20kHz; 45dB @ 25kHz
- Rated Audio Power Output
- 0.5W
- Rated Audio Distortion
- ≤3%
- Audio Response
- +1 ~ -3dB
- Conducted Spurious Emission
- < -57dBm
Transmitter
- RF Power Output
- UHFx: 1W/4W; VHF1: 1W/5W; UHF5: 1W/3W (806-870MHz) UHF5: 1W/2.5W (896-941MHz)
- FM Modulation
- 11K0F3E @ 12.5kHz 14K0F3E @ 20kHz 16K0F3E @ 25kHz
- 4FSK Digital Modulation
- 12.5kHz Data Only: 7K60FXD 12.5kHz Data & Voice: 7K60FXW
- Modulation Limiting
- ±2.5kHz @ 12.5kHz ±4.0kHz @ 20kHz; ±5.0kHz @ 25kHz
- FM Hum & Noise
- 40dB @ 12.5kHz 43dB @ 20kHz 45dB @ 25kHz
- Adjacent Channel Power
- 60dB @ 12.5kHz; 70dB @ 20/25kHz
- Audio Response
- +1 ~ -3dB
- Audio Distortion
- ≤3%
- Digital Vocoder Type
- AMBE+2™ SELP
- Digital Protocol
- ETSI-TS102 361-1,-2,-3
Environmental Specifications
- Dust & Water Intrusion
- IP68 Standard
GPS (Accuracy specs are for long-term tracking) (5 satellites visible at nominal -130dBm)
- TTFF (Time To First Fix) Cold Start
- <1 minute
- TTFF (Time To First Fix) Hot Start
- <10 seconds
- Horizontal Accuracy
- <5m (50% probable) <10m (95% probable)
