PNC550

Handheld | LTE

Highlights

diagram indicating highlights of PNC550

Rugged and Reliable

IP68 rated and 1.2m drop-proof design makes the PNC550 a suitable product to provide reliable communications at all times.

Clear Communication

The dual mic noise suppression technology and powerful voice recognition function effectively differentiate human voice in any noisy working environment. The built-in 1W speaker provides clear audio quality for versatile voice service.

High capacity battery and Fast charge

PNC550 features a 4000mAh removable battery providing communications for longer working hours and also hours and also supports 2A fast charge. The battery can be charged via a desktop charger, USB or multi-unit charger.

Dual-Sim

PNC550 supports dual-card and dual-standby. This makes it not only the PoC (PTT over Cellular) but also a smartphone. Based on 2G/3G/4G/Wi-Fi.

HD Camera

13MP rear camera and 8MP front camera provide customer with greater possibilities of image and video services.

Functions

Icon 24px Created with Sketch. Unified Management Platform

Smart MDM provides unified management of PNC550. It supports firmware upgrade, AAP push and installation remotely, and also allows management of authority for users. SmartMDM supports authentication and data encryption.

Created with Sketch. PoC Solution

PNC550 can implement versatile voice, video and data services over the public network. The dedicated PTT design make it easy to initiate instant call anytime and anywhere.

Created with Sketch. 5-Inch HD Multi-touch display

5-inch multi-touch Gorilla Glass display with 1080 x 720 WVGA resolution can be used outdoors in direct sunlight.

Img 9092

Data Acq 2 Created with Sketch. NFC Function

The built-in NFC module provides NFC related functions such as information query, authentication, identification, inspection etc.

Icon 24px Created with Sketch. Inclusive System

Integrated with the Android 8.1 system, PNC550 provides higher compatibility and security performance. It can support multiple applications. Open API and SDK allow third party development of customised applications.

Accessories for PNC550

Included as standard with PNC550 Included as standard with PNC550

Related products that work with the PNC550

Technical Specifications

Standards and Frequencies

LTE
FDD LTE: B1/B5/B7/B8/B20/B26/B27/B28 TDD LTE: B38/ B39/B40/B41
WCDMA
B1/B3/B5/B8
GSM
850/950/1800/1900MHz
WLAN
2.4GHz, 802.11 b/g/n
Bluetooth
BT 4.1
Positioning System
GPS (AGPS), Beidou/Glonass/ Galileo/Network
NFC
Support

Support Audio and Video

Audio Format
MP3: aacplus, eAAC, AMR-NB, AMR-WB, G-711, Windows media audio, (WMA) 9/10 Pro
Video and Image Format
H.263, P0, H.264, BP/MP/ HP, MPEG-4, SP/ASP, DivX, 4x/5x/6x, VP8, VP9, H.265, MP, JPG, GIF, BMP, PNG,WEbP

Environmental

Dust and Water proof
IP68
Military Standard
MIL-STD-810G
Drop Resistance
1.2m
