PD685 (Discontinuation Date: March 31st, 2024)

Handheld | DMR

Highlights

diagram indicating highlights of PD685  (Discontinuation Date: March 31st, 2024)

Rugged and Reliable

Dust and waterproof, rated IP67, sustaining performance in harsh environments

Systems Connectivity

Versatile to connect with telemetry, integrate into telephony, or expand across multiple sites with Hytera XPT or DMR Tier III (licenced)

Safer Workforce

Emergency mode, priority interrupt and lone worker features are provided as standard

GPS Location

Available as an optional extra, GPS for tracking and positioning also includes man down feature

Long Battery Life

Operating time of approximately 16 hours in digital mode

Functions

Created with Sketch. Pseudo Trunking

Using pseudo-trunking, a Hytera patented technology, slots can be shared to improve capacity usage with transmissions either direct to handset or to repeater.

Created with Sketch. XPT

Hytera XPT (Extended Pseudo Trunking) enables you to use limited spectrum resources more efficiently, dynamically assigning channel resource without needing a dedicated control channel.

Created with Sketch. Emergency Mode

Raise an alarm with top priority to a base station or to other radios with the pre-programmed emergency mode, identifying the ID of the person issuing the alarm. Also receive emergency notifications.

Created with Sketch. Lone Worker

The Lone Worker feature uses a timer in the radio to measure inactivity. If the timer expires, a warning is issued, and if there is no response to that, the alarm is triggered.

Pd68 X 1

Created with Sketch. GPS

Optional (PD685G only), enabling location based services to improve safety and control.

Created with Sketch. Bluetooth Audio

Optional (external adapter accessory), wireless connectivity to audio devices to improve user experience.

Created with Sketch. Man Down

Optional (PD685G only), the man down feature will let you know if the radio has been tilted past a certain angle. This may happen for instance if the radio user has fallen over or is unconscious or injured. The alarm will be triggered after a warning is issued to the user.

Accessories for PD685 (Discontinuation Date: March 31st, 2024)

Included as standard with PD685  (Discontinuation Date: March 31st, 2024) Included as standard with PD685 (Discontinuation Date: March 31st, 2024)

Antenna

Battery

Charger & Power

Mounting

Carrying

Audio

Cables

Related products that work with the PD685 (Discontinuation Date: March 31st, 2024)

Technical Specifications

General

Frequency Range
VHF: 136-174MHz UHF1: 400-527MHz
Channel Capacity
1024 (64 zones with 256 channels per zone)
Digital Protocol
ETSI-TS102 361-1,2 & 3
Battery Life (5-5-90 Duty Cycle)
1500mAh, Analogue 11h, Digital 16h
Dimensions(W×H×D)
122 x 54 x 27mm
Weight
Approx 310g (1500mAh Li-ion)
Display
160 x 128 pixels, 65536 colours 1.8 inch, 4 rows
Keypad
Full Keypad
Programmable Buttons
3

Environmental Specifications

Dust & Water Intrusion
IP67 Standard

Features

RRS
YES
Telemetry
YES
Option Board
NO
Intrinsically Safe Option
NO
Radio Check
YES
Alert Call
YES
Stun / Unstun
YES
Remote Monitor
YES
Priority Interrupt
YES
IP Site Connect
YES
Roaming
YES
Work Order
YES
5 Tone Signalling
YES
2 Tone Signalling
YES
HDC1200 Signalling
YES
DTMF (Phone Patch)
YES
Intelligent audio
YES
VOX
YES
Priority Scan
YES
GPS SMS
PD685G only
Vibration
NO
Scrambler (Analogue)
YES
Digital Encryption
Basic encryption as standard (10, 32 & 64 character keys). 40 bit Enhanced Encryption as Standard (requires latest firmware)Advanced encryption (Hytera or DMRA 128 bits and 256bits AES) available via chargeable licence file.
Multiple Key Encryption Decode
YES
Multilanguage Menu
NO
Power on & off user logo programming
YES
Voice Interrupt
Yes (TX Interrupt for voice call, emergency call, remote dekey, text message.)
No of Contacts (Conventional)
Digital 1024 Analogue 2-Tone 32 Analogue HDC1200 200 Analogue 5-Tone 255
No of Contacts (Trunking)
Private Contacts 512 Group Contacts 1024
Text Messaging
256 characters (via Quick Text only)
Quick Text Messages
Up to 25 pre-programmed via CPS
MPT1327 / 1343 Trunking
Yes via free of charge licence file (requires latest firmware)
Tier 3 Trunking
Available via chargeable licence file (requires latest firmware)
XPT
Yes via smartdispatch 4.0
Over-the-Air Programming
Not Available
Full Duplex Calls
NO
Micro SD Card
NO
Voice Recording
NO
Data Services via Bluetooth
NO
Single Frequency Repeater
NO
Auto Power Select
Yes (V8.0 firmware or later)
