RD985 (Discontinuation Date: March 31st, 2024)
Highlights
Comprehensive Network
All the repeaters from Hytera can be connected in digital mode via IP connection for multi-site requirements. Both in conventional analogue and DMR modes (DMR Tier II), the RD985S repeater can be used with the RD625 and RD965 repeaters to create an impressive network
Flexible Installation
The RD985 can be installed in a 19-inch equipment rack or a work table
Maximise Capacity
Thanks to the TDMA technology, twice as many users can use the same channel. With frequency scarcity, this represents an important relief and reduces the expense of system terminals and licenses
Professional Design
Integrated LEDs complement the sleek repeater design, while the integrated fan assembly provides high cooling capacity. Created with an intuitive interface, clear menus and the large navigation controller ensure it's simple to use
Secure Communication
Offering advanced digital encryption function, the RD985 can switch independently between digital and analogue modes, yet always ensuring the signal is protected
Functions
Mixed Mode Operation
This feature allows the device to automatically detect and switch between analogue and digital modes based on the signal received.
IP Site Connect
Create and control your network using IP (internet protocol) site connect.
Digital Encryption
40 bit enhanced encryption as standard with the latest firmware, ensuring your transmissions are secure.
Pseudo Trunking
Using pseudo-trunking, a Hytera patented technology, slots can be shared to improve capacity usage with transmissions either direct to handset or to repeater.
Accessory Connector
Port to connect a multitude of audio accessory options, improving the user operating experience in different environments.
Accessories for RD985 (Discontinuation Date: March 31st, 2024)
Included as standard with RD985 (Discontinuation Date: March 31st, 2024)
Mounting
Cables
Audio
Charger & Power
Other
Related products that work with the RD985 (Discontinuation Date: March 31st, 2024)
Technical Specifications
General
- Frequency Range
- VHF: 136-174MHz UHF1: 400-470MHz UHF2: 450-520MHz
- Channel Capacity
- 16
- Digital Protocol
- ETSI-TS102 361-1,2 & 3
- Supply Voltage
- DC +13.6v ± 15%
- Battery Backup
- YES via PSU
- Integral Battery Charging
- YES via PSU
- Dimensions(W×H×D)
- 88 x 483 x 366 (mm)
- Weight
- 8.5Kg
- Display
- 2.0'' 4 rows 160*128 pixels 262200 colours
- Programmable Buttons
- 4
- TX Aerial Connector
- N-type socket
- RX Aerial Connector
- N-type socket
- Internal Duplexer
- YES using optional mounting kit
Features
- 19" Rack Mounting
- YES (2U required)
- Back Pack
- NO
- Multiple CTCSS/ CDCSS
- YES
- Repeater Knockdown
- YES (Analogue & Digital)
- IP Ports
- 1
- GPS
- NO
- Telemetry
- YES
- Audio Output for Slot A & B
- YES
- Remote Programming
- YES via IP interface
- Remote Diagnostic & Control
- Software available
- Emergency Mode
- NO
- Lone Worker
- NO
- Mandown
- NO
- Priority Scan
- YES
- Digital Encryption
- Advanced encryption (Hytera or DMRA 128 bits and 256bits AES) available via chargeable licence file.
- Multiple Key Encryption Decode
- YES
- Multilanguage Menu
- YES
- Power on & off user logo programming
- YES
- Voice Interrupt
- Yes (latest firmware required and Smart Dispatch V4.5.6)
- Text Messaging
- Yes via application software
- Quick Text Messages
- Up to 25 pre-programmed via CPS (for telemetry use)
- MPT1327 / 1343 Trunking
- NO
- Tier 3 Trunking
- NO
- Single Site XPT
- NO
- Multi-Site XPT
- NO
- Number of Sites
- NO
- Over-the-Air Programming
- NO
- Analogue Only Version
- Not Available
